Product Details
Specifications
BOM
Where Used
Reference Material
Part Interchange
Status:
Active
Weight:
12.40
Unit Pack:
1
Pallet Quantity:
100
UPC Code:
737238311232
Brand:
Meritor Genuine
Marketing Group:
18N Series
Bearing Cap Diameter:
1.94 in.
Yoke Dimension Across Ears:
7.55 in.
Series:
18N
Insert Diameter:
4.24 in.
Center To Weld Point:
3.38 in.
Center To End:
4.63 in.
Use W/ Tubing OD And Wall:
4.50 in. x .134 in. (10 GA)
Joint Angle:
30 degrees
Use U-Joint Kit:
M281X or M676X
VMRS Code:
024-002-057
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|---|
| 18XND903B000BOM | ASSEMBLY-DOUBLE COUPLING |
| 18XND903B000HBOM | ASSEMBLY-DOUBLE COUPLING |
| 18XXD072B420BOM | JOINT-2,NON SLIP |
| 18XXD072B000BOM | JOINT-2,NON SLIP |
| 18NND903B110BOM | JOINT-2,NON SLIP |
| 18NND903B512BOM | JOINT-2,NON SLIP |
| 18NND903B000BOM | JOINT-2,NON SLIP |
| 18NND903B000HBOM | JOINT-2,NON SLIP |
| 18NNC013B036BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B051BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B056BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B069BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B076BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B079BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC014B084BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC014B074BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC014B089BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC014B069BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC014B079BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC014B064BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013B064BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013B029BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013B088BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC014E622BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC080B373BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B393BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B423BOM | YK, TUBE & STUB W:CTR PARTS |
| 18NNC013B026BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B041BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B031BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B029BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B034BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B064BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B074BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC080B408BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XNC080B573BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XNC080B543BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XNC080B308BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XNC080B503BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC014E681BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC080B473BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B483BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC014E572BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC014E651BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC014E553BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC080B353BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B453BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC014E612BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC080B328BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B398BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC014E405BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC014E671BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC080B228BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B358BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B463BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC014E464BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC080B488BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B603BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B628BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC081B468BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B458BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B588BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B503BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B543BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B573BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B583BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B378BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B648BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B508BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B413BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B633BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC014E592BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XTC080B388BOM | YK, TUBE & STUB W:CTR PARTS |
| 18XTC080B658BOM | YK, TUBE & STUB W:CTR PARTS |
| 18NNC013B081BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B049BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B066BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B071BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B084BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B039BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B061BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B086BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B044BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B046BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B054BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B089BOM | YK, TUBE & STUB W/CTR PARTS |
| 18NNC013B059BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013B074BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013B084BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013C073BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013C084BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013C063BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013C078BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013C083BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013C064BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013C068BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013C074BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013C088BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013E084BOM | YK, TUBE & STUB W/CTR PARTS |
| 18XNC013E074BOM | YK, TUBE & STUB W/CTR PARTS |
| Reference Material: |
For measuring guideline instructions: Click here
|
| Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Dana
6528117, 6528117
Neapco
N6528117
Other
027010258, 1662162C1, 18N28117RI, 418320C1, 6528117R, 823518N28117, ATI18N28117, D6528117, DM6528117R, DS6528117, E6528117, HR18N28117, MER18N28117, S7455, SI6528117, TDA18N28117
Model
