Product Details
Specifications
BOM
Where Used
Production BOM
Reference Material
Part Interchange
Status:
Active
Weight:
3.15
Unit Pack:
1
Pallet Quantity:
56
UPC Code:
737238769118
Brand:
Meritor Genuine
Marketing Group:
Dust Shields
Brake Diameter:
16.50 in.
Brake Model:
P and Q Series
Mount:
Screw/Cap Screw
Suspension Model:
Multiple
Application Information:
Use on 16-1/2 in. x 7 in. P and Q brakes.
Brake Size:
16.50 in. x 7.00 in.
Brake Shoe Width:
7.00 in.
Offset:
1.50 in.
Inner Diameter:
10.125 in.
Outer Diameter:
18.125 in.
VMRS Code:
013-017-000
Hole Size:
0.4375 in.
Lip Height:
0.656 in.
Number of Mounting Holes:
06
Bill of Materials:
Part No
Quantity
Description
Bill of Materials:
Part No
Quantity
Description
| Xpress Facts: |
Wheel End Product Information
|
Competitor
Part Number
Other
8235MPS3980, ATIMPS3980, TDAMPS3980
