Product Details
Specifications
BOM
Where Used
Production BOM
Reference Material
Part Interchange
Status:
Active
Weight:
3.87
Unit Pack:
1
Pallet Quantity:
56
UPC Code:
884879747736
Brand:
Meritor Genuine
Marketing Group:
Dust Shields
Brake Diameter:
16.50 in.
Brake Model:
P and Q Series
Mount:
Screw/Cap Screw
Suspension Model:
Multiple
Brake Shoe Width:
8.625 in.
Offset:
1.41 in.
Application Information:
For use with Cast Spiders
Brake Size:
16.50 in. X 8.625 in.
Inner Diameter:
10.125 in.
Outer Diameter:
18.125 in.
Hole Size:
0.4375 in.
VMRS Code:
013-017-000
Lip Height:
0.300 in.
Number of Mounting Holes:
06
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|---|
| QP416582211BOM | BRAKE ASSY |
| QP616581098BOM | BRAKE ASSY |
| QP616581097BOM | BRAKE ASSY |
| QP416582212BOM | BRAKE ASSY |
| QP616581843BOM | BRAKE ASSY |
| QP616581844BOM | BRAKE ASSY |
| QP416581654BOM | BRAKE ASSY |
| QP416582140BOM | BRAKE ASSY |
| QP616581845BOM | BRAKE ASSY |
| QP616582091BOM | BRAKE ASSY |
| QP416582114BOM | BRAKE ASSY |
| QP616581846BOM | BRAKE ASSY |
| QP416582167BOM | BRAKE ASSY |
| QP416582149BOM | BRAKE ASSY |
| QP416582113BOM | BRAKE ASSY |
| QP416582139BOM | BRAKE ASSY |
| QP416581653BOM | BRAKE ASSY |
| QP416582168BOM | BRAKE ASSY |
| QP416582150BOM | BRAKE ASSY |
| QP616582092BOM | BRAKE ASSY |
| QP416582803BOM | BRAKE ASSY |
| CP41658930BOM | BRAKE ASSY |
| CP41658915BOM | BRAKE ASSY |
| CP41658929BOM | BRAKE ASSY |
| CP41658921BOM | BRAKE ASSY |
| CP41658922BOM | BRAKE ASSY |
| QP416582804BOM | BRAKE ASSY |
| CP41658636BOM | BRAKE ASSY |
| CP41658635BOM | BRAKE ASSY |
| CP41658525BOM | BRAKE ASSY |
| CP41658916BOM | BRAKE ASSY |
| CP41658526BOM | BRAKE ASSY |
Bill of Materials:
Part No
Quantity
Description
| Xpress Facts: |
Wheel End Product Information
|
Competitor
Part Number
Other
85145231, MERKIT12109, TDAKIT12109
