Exclusive - Distributor Channel
Qty
Locate Dealer / Distributor
Product Details
Specifications
Where Used
Reference Material
Part Interchange
Alternate
Status:
Active
Weight:
11.60
Unit Pack:
1
Pallet Quantity:
80
UPC Code:
729374129154
Brand:
Euclid
Marketing Group:
Unlined Shoes
Lining Number:
Unlined
Lining Weight Rating:
NA
Brake Diameter:
16.50 in.
Brake Shoe Width:
7.00 in.
FMSI:
4707
OE Mfg.:
Meritor
Application Information:
Meritor Q Plus Brake. NOTE: Euclid recommends using only Heavy-Duty Return Springs with Q Plus Brakes.
Rivet Number:
43017
Aftermarket Brake Shoe:
R4707
Brake Shoe Repair Kit:
E-2769 Series
Rivet Hole Count:
28
Rivet Size:
0.25 in.
Friction Type:
Unlined
Brake Type:
Q Plus
VMRS Code:
013-002-013
| Part Number | Description |
|---|
| Catalog: |
100AB - Euclid Brake and Wheel End Catalog
|
| Xpress Facts: |
Brake Shoes & Lining Product Information
|
Competitor
Part Number
Automann
14247028, 142470780, 142470782
BWP
M3189
Spicer
21855, 4707R, 4707XT
Other
A3222D2006
Model
