Status:
Active
Weight:
12.24
Unit Pack:
1
Pallet Quantity:
96
UPC Code:
729374640178
Brand:
Euclid
Marketing Group:
Camshafts
Brake Diameter:
12.25 in.
Camshaft Spline Diameter:
1.50 in.
Camshaft Spline Count:
28
Bushing Journal Length:
2.22 in.
Effective Length:
20.56 in.
Left or Right:
RH
Head Type:
05
OE Mfg.:
Dana-Spicer
Paired Camshaft:
E10901
Axle:
Trailer
Camshaft Repair Kit:
E9790A
Brake Hardware Kit:
E9283, E10756, E10757, E14539
Brake Type:
Xtralife
VMRS Code:
013-017-004
Notes:
0794L/R Head Fast-Rise. Euclid fabricated open roller end brake shoe numbers are: E-2393A, E-2394A, and E-5303A
Mfg. Part:
Dana-Spicer M12WKR25-206
Application Information 1:
WARNING: These camshafts are for use with fabricated brakes shoes only! DO NOT use these new camshafts with cast brake shoe or fabricated closed roller-end brake shoes., WARNING: These camshafts are for use with fabricated brakes shoes only! DO NOT use these new camshafts with cast brake shoe or fabricated closed roller-end brake shoes.
Application Information 2:
WARNING: E-586, 1-1/2 in. Diameters, Brake Shoe Rollers must be used with this new head design. E-586 rollers are now available in Brake Repair Kits E-9281, E-9282 and E-9283., WARNING: E-586, 1-1/2 in. Diameters, Brake Shoe Rollers must be used with this new head design. E-586 rollers are now available in Brake Repair Kits E-9281, E-9282 and E-9283.
Application Information 3:
WARNING: These camshafts should not be used in conjunction with old Fast-Rise camshafts on the same axle. The rate of brake application is different between the two head designs., WARNING: These camshafts should not be used in conjunction with old Fast-Rise camshafts on the same axle. The rate of brake application is different between the two head designs.
| Part Number | Description |
|---|
| Catalog: |
100AB - Euclid Brake and Wheel End Catalog
|
| Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
| Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
| Sales Publication: |
SP1980 - The Complete Brake Job
|
| Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
| Xpress Facts: |
Air Brake Product Information
|
Competitor
Part Number
Automann
12328201802
BWP
M3794R
Hercules
H10879R
Nuturn - CAN
L3268
Spicer
17402, M12WKR25206
