Product Details
Specifications
BOM
Where Used
Production BOM
Reference Material
Part Interchange
Status:
Active
Weight:
18.00
Unit Pack:
1
Pallet Quantity:
48
UPC Code:
737238472025
Brand:
Meritor Genuine
Marketing Group:
Lined Shoes
New or Reman:
New
Brake Shoe Width:
7.00 in.
Lining Number:
R301
Brake Diameter:
16.50 in.
Lining Type:
Meritor Production
FMSI:
4707QP
OE Mfg.:
Meritor
Reman Shoe:
SR3014707QP
Brake Shoe Repair Kit:
KIT 8000HD
Application Information:
Meritor Q Plus; Rear axle - truck, tractor, trailer
Rivet Size:
0.25 in.
Aftermarket Brake Shoe:
R4707
Brake Type:
Q Plus
Rivet Hole Count:
28
VMRS Code:
013-002-012
Bill of Materials:
Part No
Quantity
Description
Bill of Materials:
Part No
Quantity
Description
| Xpress Facts: |
Brake Shoes & Lining Product Information
|
Competitor
Part Number
Other
1693187C91, 8235A13222D2006, A13222D2006RI, ATIA13222D2006, TDAA13222D2006
Model
