Status:
Active
Weight:
9.93
Unit Pack:
1
Pallet Quantity:
180
UPC Code:
737238624943
Brand:
Meritor Genuine
Marketing Group:
Camshafts
Brake Type:
Q Plus
Camshaft Spline Count:
28
Bushing Journal Length:
1.77 in.
Effective Length:
15.70 in.
Brake Diameter:
16.50 in.
Camshaft Spline Diameter:
1.50 in.
Left or Right:
LH
OE Mfg.:
Meritor
Head Type:
11
Paired Camshaft:
2210R7688
Axle:
Drive or Steer
Brake Hardware Kit:
KIT8000HD
Camshaft Repair Kit:
KIT8042
VMRS Code:
013-017-004
Catalog: |
PB8857 - Meritor Drum Brake and Wheel End Catalog
|
Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
Sales Publication: |
SP1980 - The Complete Brake Job
|
Xpress Facts: |
Air Brake Product Information
|
Competitor
Part Number
Automann
12228152301, 12228152303
Dayton Parts Batco
04481572
Hercules
H10778L, HQ10342L
Spicer
18543
Other
2210S7689RI, 82352210S7689, ATI2210S7689, BWPM3117L, BWPM4008L, C683L, CAM206L, CS9683L, EUE9683, L3331, L3507, M4008L, MER2210S7689, RW2210S7689, TDA2210S7689, TW04481572
