Status:
Active
Weight:
13.50
Unit Pack:
1
Pallet Quantity:
100
UPC Code:
737238797555
Brand:
Meritor Genuine
Marketing Group:
RPL20 Series
Series:
RPL20
Spline Diameter:
2.024 in.
Number of Splines:
39I
Hub Diameter:
3.00 in.
Spline Length:
2.31 in.
Counter Bore Depth:
0.09 in.
Joint Angle:
45 degrees
Use U-Joint Kit:
CP20RPLS
Face To End:
5.95 in.
Bearing Cap Diameter:
2.06 in.
VMRS Code:
024-001-003
Use Kit:
KIT RPL 25 20
Yoke Dimension Across Nibbs:
7.06 in.
Part Number | Description |
---|---|
END YOKE | |
END YOKE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE |
Reference Material: |
For measuring guideline instructions: Click here
|
Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Neapco
N20WYS322
Other
20504479, 20WYS322RI, 823520WYS322, ATI20WYS322, HR20WYS322, S19116, TDA20WYS322
