Status:
Active
Weight:
15.75
Unit Pack:
1
UPC Code:
737238711902
Brand:
Meritor Genuine
Marketing Group:
18N Series
Spline Diameter:
2.390 in.
Series:
18N
Number of Splines:
46I
Hub Diameter:
3.25 in.
Spline Length:
2.88 in.
Center To End:
5.69 in.
Joint Angle:
32 degrees
Use U-Joint Kit:
M281X
Counter Bore Depth:
0.14 in.
Deflector:
DEFR54-5
Comments:
Dana Spline - 2.374 in.-46
Yoke Dim. Across Ears:
7.55 in.
Bearing Cap Diameter:
1.94 in.
VMRS Code:
024-001-003
Part Number | Description |
---|---|
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
REAR SINGLE AXLE CARRIER | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE | |
AXLE ASSY-DRIVE |
Reference Material: |
For measuring guideline instructions: Click here
|
Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Dana
6543581X, 6543581X
Other
18N43581XRI, 3945191, 823518N43581X, ATI18N43581X, SI6543581X, TDA18N43581X
Model
