Product Details
Specifications
Where Used
Reference Material
Part Interchange
Status:
Active
Weight:
15.14
Unit Pack:
1
Pallet Quantity:
100
UPC Code:
737238647621
Brand:
Meritor Genuine
Marketing Group:
17N Series
Series:
17N
Number of Splines:
46I
Spline Diameter:
2.390 in.
Hub Diameter:
3.25 in.
Spline Length:
2.88 in.
Center To End:
6.93 in.
Use U-Joint Kit:
M280X
Joint Angle:
45 degrees
Counter Bore Depth:
0.14 in.
Bearing Cap Diameter:
1.94 in.
Yoke Dim. Across Ears:
6.09 in.
VMRS Code:
024-001-003
| Part Number | Description |
|---|---|
| RP26185NFNN37489BOM | AXLE ASSY-DRIVE |
| SUB17N47851X | END YOKE |
| RP26185NFNN37430BOM | AXLE ASSY-DRIVE |
| A303200K1753538BOM | CARR ASSY-DIFF,LOCKOUT |
| A303200K1753614BOM | CARR ASSY-DIFF,LOCKOUT |
| A303200K1753563BOM | CARR ASSY-DIFF,LOCKOUT |
| A233200K1753489BOM | CARR ASSY-DIFF,NON LOCKOUT |
| A233200K1753614BOM | CARR ASSY-DIFF,NON LOCKOUT |
| A233200K1753538BOM | CARR ASSY-DIFF,NON LOCKOUT |
| A233200K1753683BOM | CARR ASSY-DIFF,NON LOCKOUT |
| 17NYS3863AIBOM | YOKE & DEFLECTOR ASSY |
| 17NYS3863A1IBOM | YOKE & DEFLECTOR ASSY |
| Reference Material: |
For measuring guideline instructions: Click here
|
| Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Dana
645921
Other
647831, 823517NYS3863, TDA17NYS3863
Model
