Status:
Active
Weight:
16.40
Unit Pack:
1
UPC Code:
737238648727
Brand:
Meritor Genuine
Marketing Group:
17N Series
Number of Splines:
46
Spline Diameter:
2.374 in.
Series:
17N
Hub Diameter:
3.25 in.
Spline Length:
2.88 in.
Center To End:
5.94 in.
Distance Between Nibbs:
6.19 in.
Joint Angle:
34 degrees
Use U-Joint Kit:
M675X
Counter Bore Depth:
0.14 in.
Kit Mtg. Holes:
TH
Deflector:
DEFR54-5
Bearing Cap Diameter:
1.94 in.
VMRS Code:
024-001-003
Use Kit:
KT17SB
| Part Number | Description |
|---|---|
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE | |
| AXLE ASSY-DRIVE |
| Reference Material: |
For measuring guideline instructions: Click here
|
| Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Dana
6469611X, 6469611X
Other
17N469611XRI, 823517N469611X, ATI17N469611X, SI6469611X, TDA17N469611X
