Product Details
Specifications
BOM
Where Used
Reference Material
Part Interchange
Alternate
Status:
Active
Weight:
6.32
Unit Pack:
1
Pallet Quantity:
280
UPC Code:
737238851837
Brand:
Meritor Genuine
Marketing Group:
Meritor
Piston:
Red Piston
Clevis Type:
Unclevised
Type:
Type 1
Arm Length:
5.50 in.
Slack Spline Diameter:
1.25 in.
Slack Spline Count:
24
Aftermarket Extended Warranty - General:
3 Years / Unlimited Miles
Sensing Type:
Stroke
OEM:
Meritor
Aftermarket Extended Warranty - Heavy Se:
3 Years / Unlimited Miles
Aftermarket Extended Warranty - Linehaul:
5 Years / 500K Miles
Model:
Meritor
Aftermarket Extended Warranty - Off-High:
3 Years / Unlimited Miles
Chamber Sizes:
20
Notes:
Red piston. Drum brake. Special grease fitting locations.
VMRS Code:
013-017-005
Maximum Torque Rating:
More than 45 inch pounds
Related Clevis Kit:
R810008
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|
| Catalog: |
PB8857 - Meritor Drum Brake and Wheel End Catalog
|
| Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
| Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
| Sales Publication: |
SP1638 - Meritor AllFit SimpleCheck Brake Stroke Tool
|
| Sales Publication: |
SP15102 - Meritor Stroke Sensing Automatic Slack Adjusters for the Aftermarket
|
| Sales Publication: |
SP1980 - The Complete Brake Job
|
| Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
| Warranty Information: |
SP16165 - Meritor Aftermarket Warranty
|
| Video: |
Meritor Stroke ASA Video
|
| Xpress Facts: |
Air Brake Product Information
|
Competitor
Part Number
Other
2018225C91, 3949820, 8235R803070, ATIR803070, CS52336, HRR803070, MERR803070, R803070RI, ROR803070, RWR803070, TDAR803070
Model
