Status:
Active
Weight:
6.27
Unit Pack:
1
Pallet Quantity:
280
UPC Code:
737238837305
Brand:
Meritor Genuine
Marketing Group:
Meritor
Clevis Type:
Unclevised
Type:
Type 2
Piston:
Green Piston
Arm Length:
6.00 in.
Slack Spline Diameter:
1.50 in.
Slack Spline Count:
28
OE or AllMakes:
OE
Aftermarket Extended Warranty - Heavy Se:
3 Years / Unlimited Miles
Aftermarket Extended Warranty - Linehaul:
5 Years / 500K Miles
Model:
Meritor
OEM:
Meritor
Aftermarket Extended Warranty - General:
3 Years / Unlimited Miles
Sensing Type:
Stroke
Aftermarket Extended Warranty - Off-High:
3 Years / Unlimited Miles
Chamber Sizes:
36
VMRS Code:
013-017-005
Notes:
Green piston. Drum brake.
Maximum Torque Rating:
More than 45 inch pounds
Related Clevis Kit:
R810009
Bill of Materials:
Part No
Quantity
Description
Part Number | Description |
---|---|
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY | |
BRAKE ASSY |
Catalog: |
PB8857 - Meritor Drum Brake and Wheel End Catalog
|
Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
Sales Publication: |
SP1638 - Meritor AllFit SimpleCheck Brake Stroke Tool
|
Sales Publication: |
SP15102 - Meritor Stroke Sensing Automatic Slack Adjusters for the Aftermarket
|
Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
Sales Publication: |
SP1980 - The Complete Brake Job
|
Warranty Information: |
SP16165 - Meritor Aftermarket Warranty
|
Video: |
Meritor Stroke ASA Video
|
Xpress Facts: |
Air Brake Product Information
|
Competitor
Part Number
Other
3947655, 8235R803057, ATIR803057, MERR803057, R803057RI, RIR803057, ROR803057, TDAR803057, TWDR803057
Model
