Product Details
Specifications
BOM
Where Used
Reference Material
Part Interchange
Alternate
Visual Search
Status:
Active
Weight:
6.93
Unit Pack:
1
Pallet Quantity:
280
UPC Code:
737238562825
Brand:
Meritor Genuine
Marketing Group:
Meritor
Clevis Type:
Straight
Piston:
Yellow Piston
Type:
Type 2
Production Part Number:
A14-3275-C-1147
Arm Length:
6.00 in.
Slack Spline Diameter:
1.50 in.
Slack Spline Count:
28
Aftermarket Extended Warranty - Heavy Se:
3 Years / Unlimited Miles
Aftermarket Extended Warranty - Off-High:
3 Years / Unlimited Miles
Aftermarket Extended Warranty - Linehaul:
5 Years / 500K Miles
Sensing Type:
Stroke
Model:
Meritor
Aftermarket Extended Warranty - General:
3 Years / Unlimited Miles
OEM:
Meritor
Chamber Sizes:
30
VMRS Code:
013-017-005
Notes:
Yellow piston. Drum brake.
Clevis Thread Diameter:
0.625 in.
Clevis Threads per inch:
18
Maximum Torque Rating:
More than 45 inch pounds
Related Unclevised Number:
R803055
Related Clevis Kit:
R810019
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|---|
| QP2165712040BOM | BRAKE ASSY |
| QP2165712452BOM | BRAKE ASSY |
| QP2165712512BOM | BRAKE ASSY |
| QP2165712510BOM | BRAKE ASSY |
| QP2165712482BOM | BRAKE ASSY |
| QP2165712534BOM | BRAKE ASSY |
| QP2165712535BOM | BRAKE ASSY |
| QP2165713674BOM | BRAKE ASSY |
| QP2165713669BOM | BRAKE ASSY |
| QP2165714011BOM | BRAKE ASSY |
| QP2165712997BOM | BRAKE ASSY |
| QP2165715657BOM | BRAKE ASSY |
| Catalog: |
PB8857 - Meritor Drum Brake and Wheel End Catalog
|
| Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
| Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
| Sales Publication: |
SP1980 - The Complete Brake Job
|
| Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
| Sales Publication: |
SP15102 - Meritor Stroke Sensing Automatic Slack Adjusters for the Aftermarket
|
| Sales Publication: |
SP1638 - Meritor AllFit SimpleCheck Brake Stroke Tool
|
| Warranty Information: |
SP16165 - Meritor Aftermarket Warranty
|
| Video: |
Meritor Stroke ASA Video
|
| Xpress Facts: |
Air Brake Product Information
|
Competitor
Part Number
Other
1090263, 4L664, 8235R802487, ASM802487, ATIR802487, ATXR802487, BXK041877, GUAS1141, HRR802487, R802487RI, ROR802487, RWR802487, TDAR802487, TWDR802487, V1090263, ZBRAS1141
