Product Details
Specifications
BOM
Reference Material
Part Interchange
Alternate
Visual Search
Status:
Active
Weight:
6.77
Pallet Quantity:
280
UPC Code:
737238562115
Brand:
Meritor Genuine
Marketing Group:
Meritor
Piston:
Yellow Piston
Production Part Number:
A27-3275-Z-1144
Clevis Type:
Straight
AllMakes or OE:
OE
Type:
Type 1
Arm Length:
5.50 in.
Slack Spline Diameter:
1.50 in.
Slack Spline Count:
10
Aftermarket Extended Warranty - General:
3 Years / Unlimited Miles
Aftermarket Extended Warranty - Off-High:
3 Years / Unlimited Miles
Aftermarket Extended Warranty - Heavy Se:
3 Years / Unlimited Miles
Model:
Meritor
Aftermarket Extended Warranty - Linehaul:
5 Years / 500K Miles
OEM:
Meritor
Sensing Type:
Stroke
Chamber Sizes:
30
Notes:
Yellow piston. Drum brake.
VMRS Code:
013-017-005
Clevis Thread Diameter:
0.625 in.
Clevis Threads per inch:
18
Maximum Torque Rating:
More than 45 inch pounds
Related Unclevised Number:
R803024
Related Clevis Kit:
R810019
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|
| Catalog: |
PB8857 - Meritor Drum Brake and Wheel End Catalog
|
| Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
| Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
| Sales Publication: |
SP15102 - Meritor Stroke Sensing Automatic Slack Adjusters for the Aftermarket
|
| Sales Publication: |
SP1980 - The Complete Brake Job
|
| Sales Publication: |
SP1638 - Meritor AllFit SimpleCheck Brake Stroke Tool
|
| Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
| Technical Bulletin: |
TP9173A - Technical Bulletin
|
| Video: |
Meritor Stroke ASA Video
|
| Warranty Information: |
SP16165 - Meritor Aftermarket Warranty
|
| Xpress Facts: |
Air Brake Product Information
|
Competitor
Part Number
Other
3133370, 8235R802316, 9628R802316, ATIR802316, BXK041870, R802316RI, ROR802316, TDAR802316, TWDR802316, ZBRAS1132
Model
R802316
AIR BRAKE - ASA - MERITOR
Qty
