Product Details
Specifications
BOM
Where Used
Reference Material
Part Interchange
Alternate
Visual Search
Status:
Active
Weight:
6.80
Unit Pack:
1
Pallet Quantity:
280
UPC Code:
737238548416
Brand:
Meritor Genuine
Marketing Group:
Meritor
Production Part Number:
A5-3275-J-1154
Type:
Unhanded
Clevis Type:
Straight
Piston:
Yellow Piston
Arm Length:
6.00 in.
Slack Spline Diameter:
1.50 in.
Slack Spline Count:
10
Aftermarket Extended Warranty - Linehaul:
5 Years / 500K Miles
Aftermarket Extended Warranty - General:
3 Years / Unlimited Miles
Aftermarket Extended Warranty - Off-High:
3 Years / Unlimited Miles
OE or AllMakes:
OE
Aftermarket Extended Warranty - Heavy Se:
3 Years / Unlimited Miles
Application:
Trailer
OEM:
Meritor
Model:
Meritor
Sensing Type:
Stroke
Chamber Sizes:
30
Notes:
Yellow piston. Drum brake.
VMRS Code:
013-017-005
Clevis Thread Diameter:
0.625 in.
Clevis Threads per inch:
18
Maximum Torque Rating:
More than 45 inch pounds
Related Unclevised Number:
R803106
Related Clevis Kit:
R810019
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|
| Catalog: |
PB8857 - Meritor Drum Brake and Wheel End Catalog
|
| Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
| Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
| Sales Publication: |
SP1638 - Meritor AllFit SimpleCheck Brake Stroke Tool
|
| Sales Publication: |
SP15102 - Meritor Stroke Sensing Automatic Slack Adjusters for the Aftermarket
|
| Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
| Sales Publication: |
SP1980 - The Complete Brake Job
|
| Warranty Information: |
SP16165 - Meritor Aftermarket Warranty
|
| Video: |
Meritor Stroke ASA Video
|
| Xpress Facts: |
Air Brake Product Information
|
Competitor
Part Number
Dayton Parts Batco
05360
Other
OTR801042, PLR801042, R801042RI, RBR801042, ROR801042, RWR801042, S23557, SA1042, SAPR801042, SBRMK41106S, SCSA1042, STNMK41106S, TDAR801042, TWDR801042, V1090259, WAAS1133, WAR801042, ZBRAS1133, ZBRAS1147
Model
