Product Details
Specifications
BOM
Where Used
Reference Material
Part Interchange
Visual Search
Status:
Active
Weight:
4.65
Unit Pack:
1
Pallet Quantity:
24
UPC Code:
737238982784
Brand:
Meritor
Marketing Group:
Dust Shields
Brake Model:
Multiple
Brake Diameter:
16.50 in.
Mount:
Screw/Cap Screw
Suspension Model:
Multiple
Brake Shoe Width:
6.00 in. & 7.00 in.
Brake Size:
16.50 in. X 6.00 in. & 7.00 in.
Application Information:
For Meritor trailer applications with fabricated steel spiders. Trailer Round 5.0 in. and 5.75 in. TN/TQ/TP; Services one brake. Includes mounting hardware KIT 8087.
Offset:
2.73 in.
Outer Diameter:
18.25 in.
VMRS Code:
013-017-000
Lip Height:
0.625 in.
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|
| Catalog: |
PB8857 - Meritor Drum Brake and Wheel End Catalog
|
| Xpress Facts: |
Wheel End Product Information
|
Competitor
Part Number
Dayton Parts Batco
02515
Other
02514, 2514, 2515, 3133100, 8235R009095, ATIR009095, L3160, MERR009095, R009095RI, RIR009095, ROR009095, RWR009095, TDAR009095, TWDR009095
Model
