Exclusive - Distributor Channel
Qty
Locate Dealer / Distributor
Product Details
Specifications
Where Used
Reference Material
Part Interchange
Alternate
Status:
Active
Weight:
11.59
Unit Pack:
1
Pallet Quantity:
96
UPC Code:
729374447760
Brand:
Euclid
Marketing Group:
Camshafts
Brake Diameter:
12.25 in.
Bushing Journal Length:
2.22 in.
Camshaft Spline Diameter:
1.50 in.
Effective Length:
21.31 in.
Camshaft Spline Count:
28
Left or Right:
RH
OE Mfg.:
Dana-Spicer
Head Type:
05
Axle:
Trailer
Brake Hardware Kit:
E10757 (With 1 in. O.D. Anchor Pin, E10756 (With 1.25 in. O.D. Anchor Pin)
Paired Camshaft:
E9755
Camshaft Repair Kit:
E2469 (Nylon Bushing); E5307 Bronze Spider Bushing
Brake Type:
High-Lift
VMRS Code:
013-017-004
Notes:
0794L/R Head Fast-Rise. Euclid fabricated open roller end brake shoe numbers are: E-2393A, E-2394A, and E-5303A
Mfg. Part:
Dana-Spicer M12WKR20-214
Application Information 1:
WARNING: These camshafts are for use with fabricated brakes shoes only! DO NOT use these new camshafts with cast brake shoe or fabricated closed roller-end brake shoes., WARNING: These camshafts are for use with fabricated brakes shoes only! DO NOT use these new camshafts with cast brake shoe or fabricated closed roller-end brake shoes.
Application Information 2:
WARNING: E-586, 1-1/2 in. Diameters, Brake Shoe Rollers must be used with this new head design. E-586 rollers are now available in Brake Repair Kits E-9281, E-9282 and E-9283., WARNING: E-586, 1-1/2 in. Diameters, Brake Shoe Rollers must be used with this new head design. E-586 rollers are now available in Brake Repair Kits E-9281, E-9282 and E-9283.
Application Information 3:
WARNING: These camshafts should not be used in conjunction with old Fast-Rise camshafts on the same axle. The rate of brake application is different between the two head designs., WARNING: These camshafts should not be used in conjunction with old Fast-Rise camshafts on the same axle. The rate of brake application is different between the two head designs.
Part Number | Description |
---|
Catalog: |
100AB - Euclid Brake and Wheel End Catalog
|
Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
Sales Publication: |
SP1980 - The Complete Brake Job
|
Xpress Facts: |
Air Brake Product Information
|
Competitor
Part Number
Automann
12328211002
BWP
M3792R
D and E
D&E9756
Dayton Parts Batco
04642131
Hercules
H10483R
Spicer
M12WKR20214
