Exclusive - Distributor Channel
Qty
Locate Dealer / Distributor
Product Details
Specifications
Where Used
Reference Material
Part Interchange
Alternate
Status:
Active
Weight:
13.97
Unit Pack:
1
Pallet Quantity:
88
UPC Code:
729374238153
Brand:
Euclid
Marketing Group:
Camshafts
Camshaft Spline Diameter:
1.50 in.
Camshaft Spline Count:
28
Brake Diameter:
16.50 in.
Left or Right:
LH
Bushing Journal Length:
1.625 in.
Effective Length:
23.44 in.
OE Mfg.:
Dana-Spicer
Head Type:
01
Paired Camshaft:
E3857
Camshaft Repair Kit:
E2287
Brake Hardware Kit:
E2769HD
Axle:
Trailer
Brake Type:
Dana-Spicer
VMRS Code:
013-017-004
Notes:
Double groove journal - 1-5/8, 2-7/32. Longer Lengths for Air Ride suspensions
Mfg. Part:
Dana-Spicer M16WK104-25
Part Number | Description |
---|
Catalog: |
100AB - Euclid Brake and Wheel End Catalog
|
Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
Sales Publication: |
SP1980 - The Complete Brake Job
|
Xpress Facts: |
Air Brake Product Information
|
Competitor
Part Number
Automann
12328231401
BWP
M3186L
D and E
D&E3856
Dayton Parts Batco
04582352
Fleetpride
OTR3856
Hercules
H10422L
IMT
20127236LH, 202127236RH
Sirco Brake
C856L
Spicer
17483, M16WK10425
Trailmobile
383856
Wabash Trailer
41423856
