Product Details
Specifications
BOM
Where Used
Production BOM
Reference Material
Part Interchange
Status:
Active
Weight:
5.90
Unit Pack:
1
Pallet Quantity:
100
UPC Code:
737238701705
Brand:
Meritor Genuine
Marketing Group:
62N Series
Series:
62N
Spline Diameter:
2.024 in.
Number of Splines:
39I
Hub Diameter:
3.00 in.
Spline Length:
2.31 in.
Use U-Joint Kit:
CP62N-DWT, CP62N-HB, CP62N-HWD, or PERMALUBE
Face To End:
4.00 in.
Kit Mounting Holes: Drilled Or Threaded:
TH
Deflector:
DEFR50-7
Pilot Diameter:
5.53 in.
VMRS Code:
024-001-003
Slot Width:
0.56 in.
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|---|
| C43200L1676614BOM | CARR ASSY-DIFF,NO SPIN |
| C43200L1676463BOM | CARR ASSY-DIFF,NO SPIN |
Bill of Materials:
Part No
Quantity
Description
| Reference Material: |
For measuring guideline instructions: Click here
|
| Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Other
62NYS3248ARI, 823562NYS3248A, A3260Z1534, ATI62NYS3248A, HR62NYS3248A, TDA62NYS3248A
Model
