Product Details
Specifications
BOM
Where Used
Production BOM
Reference Material
Part Interchange
Status:
Active
Weight:
20.6
Unit Pack:
1
Pallet Quantity:
40
UPC Code:
680502102138
Brand:
Meritor Genuine
Marketing Group:
Outside Snap Rings
Number of Splines:
16
Spline Diameter:
2.500 in.
Series:
RPL20
Yoke Dimension Across Ears:
7.00 in.
Center To End:
12.05 in.
Length of Hole:
8.53 in.
Use U-Joint Kit:
CP20RPLS
Dust Cap Style:
3 Snap-On
Joint Angle:
44 degrees
Aftermarket Extended Warranty - General:
2 Years / Unlimited Miles
Related Dust Cap Group:
KIT 20RPL SEAL
VMRS Code:
024-002-038
Bearing Cap Diameter:
2.06 in.
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|---|
| 20RHM011B170BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM087F190BOM | SLIP ASSY-INNER AXLE |
| 20RHM009B165BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM010C167BOM | SLIP ASSY-INNER AXLE |
| 20RHM008B162BOM | SLIP ASSY-INNER AXLE |
| 20RHM009C165BOM | SLIP ASSY-INNER AXLE |
| 20RHM010E167BOM | SLIP ASSY-INNER AXLE |
| 20RHM012C172BOM | SLIP ASSY-INNER AXLE |
| 20RHM013E175BOM | SLIP ASSY-INNER AXLE |
| 20RHM019B190BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM015C180BOM | SLIP ASSY-INNER AXLE |
| 20RHM018B187BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM081C162BOM | SLIP ASSY-INNER AXLE |
| 20RHM018C187BOM | SLIP ASSY-INNER AXLE |
| 20RHM019C190BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM086C185BOM | SLIP ASSY-INNER AXLE |
| 20RHM020B192BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM083E170BOM | SLIP ASSY-INNER AXLE |
| 20RHM084B175BOM | SLIP ASSY-INNER AXLE |
| 20RHM086B185BOM | SLIP ASSY-INNER AXLE |
| 20RHM087E190BOM | SLIP ASSY-INNER AXLE |
| 20RHM009E165BOM | SLIP ASSY-INNER AXLE |
| 20RHM014B177BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM082E165BOM | SLIP ASSY-INNER AXLE |
| 20RHM084C175BOM | SLIP ASSY-INNER AXLE |
| 20RHM087B190BOM | SLIP ASSY-INNER AXLE |
| 20RHM012B172BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM014E177BOM | SLIP ASSY-INNER AXLE |
| 20RHM016C182BOM | SLIP ASSY-INNER AXLE |
| 20RHM016E182BOM | SLIP ASSY-INNER AXLE |
| 20RHM081E162BOM | SLIP ASSY-INNER AXLE |
| 20RHM085E180BOM | SLIP ASSY-INNER AXLE |
| 20RHM086E185BOM | SLIP ASSY-INNER AXLE |
| 20RHM013B175BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM016B182BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM017C185BOM | SLIP ASSY-INNER AXLE |
| 20RHM061B180BOM | OBSOLETE PARTS |
| 20RHM084E175BOM | SLIP ASSY-INNER AXLE |
| 20RHM085C180BOM | SLIP ASSY-INNER AXLE |
| 20RHM010B167BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM011C170BOM | SLIP ASSY-INNER AXLE |
| 20RHM012E172BOM | SLIP ASSY-INNER AXLE |
| 20RHM014C177BOM | SLIP ASSY-INNER AXLE |
| 20RHM015B180BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM018B187HBOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM082B165BOM | SLIP ASSY-INNER AXLE |
| 20RHM083C170BOM | SLIP ASSY-INNER AXLE |
| 20RHM011E170BOM | SLIP ASSY-INNER AXLE |
| 20RHM020C192BOM | SLIP ASSY-INNER AXLE |
| 20RHM020E192BOM | SLIP ASSY-INNER AXLE |
| 20RHM062B162BOM | SLIP ASSY-INNER AXLE |
| 20RHM083B170BOM | SLIP ASSY-INNER AXLE |
| 20RHM085B180BOM | SLIP ASSY-INNER AXLE |
| 20RHM087C190BOM | SLIP ASSY-INNER AXLE |
| 20RHM013C175BOM | SLIP ASSY-INNER AXLE |
| 20RHM017B185BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM020F192BOM | SLIP ASSY-INNER AXLE |
| 20RHM081B162BOM | SLIP ASSY-INNER AXLE |
| 20RHM082C165BOM | SLIP ASSY-INNER AXLE |
| 20RHM085F180BOM | SLIP ASSY-INNER AXLE |
| 20RHM008C162BOM | SLIP ASSY-INNER AXLE |
| 20RHS005B043BOM | SLIP ASSY-INNER AXLE |
| 20RHS005C067BOM | SLIP ASSY-INNER AXLE |
| 20RHS005E019BOM | SLIP ASSY-INNER AXLE |
| 20RHS005E029BOM | SLIP ASSY-INNER AXLE |
| 20RHM013B175HBOM | SLIP ASSY-INNER AXLE |
| 20RHM013E175HBOM | SLIP ASSY-INNER AXLE |
| 20RHM084E175HBOM | SLIP ASSY-INNER AXLE |
| 20RHM087E190HBOM | SLIP ASSY-INNER AXLE |
| 20RHS005B015BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM084C175HBOM | SLIP ASSY-INNER AXLE |
| 20RHM087B190HBOM | SLIP ASSY-INNER AXLE |
| 20RHM087C190HBOM | SLIP ASSY-INNER AXLE |
| 20RHM087F190HBOM | SLIP ASSY-INNER AXLE |
| 20RHS005B019BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHM020E192HBOM | SLIP ASSY-INNER AXLE |
| 20RHS005B032BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHS005E021BOM | SLIP ASSY-INNER AXLE |
| 20RHS005E025BOM | SLIP ASSY-INNER AXLE |
| 20RHS005E032BOM | SLIP ASSY-INNER AXLE |
| 20RHS005B021BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHS005B029BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHS005B360BOM | SLIP ASSY-INNER AXLE |
| 20RHS005E027BOM | SLIP ASSY-INNER AXLE |
| 20RHS005F017BOM | SLIP ASSY-INNER AXLE |
| 20RHS005F024BOM | SLIP ASSY-INNER AXLE |
| 20RHS005F027BOM | SLIP ASSY-INNER AXLE |
| 20RHS005F028BOM | SLIP ASSY-INNER AXLE |
| 20RHM020C192HBOM | SLIP ASSY-INNER AXLE |
| 20RHM020F192HBOM | SLIP ASSY-INNER AXLE |
| 20RHS060B018BOM | SLIP ASSY-INNER AXLE |
| 20RRM926B177BOM | SLIP ASSY-INNER AXLE |
| 20RHM013C175HBOM | SLIP ASSY-INNER AXLE |
| 20RHS005C030BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHS005C041BOM | SLIP ASSY-INNER AXLE |
| 20RHS005E016BOM | SLIP ASSY-INNER AXLE |
| 20RHS005F021BOM | SLIP ASSY-INNER AXLE |
| 20RHS005F030BOM | SLIP ASSY-INNER AXLE |
| 20RHS046B018BOM | SLIP ASSEMBLY-INNER AXLE |
| 20RHS059B023BOM | SLIP ASSY-INNER AXLE |
Bill of Materials:
Part No
Quantity
Description
| Reference Material: |
For measuring guideline instructions: Click here
|
| Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Neapco
N20RLS403A1S
Other
20RLS403A1S, 20RLS403A1SRI, 823520RLS403A1S, ATI20RLS403A1S, HR20RLS403A1S, MER20RLS403A1S, S17336, TDA20RLS403A, TDA20RLS403A1S
Model
