Product Details
Specifications
BOM
Where Used
Production BOM
Reference Material
Part Interchange
Status:
Active
Weight:
20.69
Unit Pack:
1
Pallet Quantity:
48
UPC Code:
680502102114
Brand:
Meritor Genuine
Marketing Group:
Outside Snap Rings
Series:
RPL20
Spline Diameter:
2.500 in.
Number of Splines:
16
Yoke Dimension Across Ears:
7.00 in.
Length of Hole:
9.23 in.
Center To End:
12.15 in.
Dust Cap Style:
3 Snap-On
Joint Angle:
32 degrees
Use U-Joint Kit:
CP20RPLS
Related Dust Cap Group:
KIT 20RPL SEAL
VMRS Code:
024-002-038
Bearing Cap Diameter:
2.06 in.
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|---|
| KIT20RSLIP | DRIVELINE - SLIP JOINT ASSEMBLY |
| KIT20RCOUP | AXLE HARDWARE - COUPLING ASSEMBLY |
Bill of Materials:
Part No
Quantity
Description
| Reference Material: |
For measuring guideline instructions: Click here
|
| Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Other
20RLS4011A1SRI, 823520RLS4011A1S, HR20RLS4011A1S, S18701, TDA20RLS4011A1S
Model
