Product Details
Specifications
BOM
Where Used
Reference Material
Part Interchange
Status:
Active
Weight:
14.80
Unit Pack:
1
Pallet Quantity:
64
UPC Code:
737238649014
Brand:
Meritor Genuine
Marketing Group:
18N Series
Number of Splines:
46I
Spline Diameter:
2.390 in.
Series:
18N
Hub Diameter:
3.25 in.
Spline Length:
2.32 in.
Center To End:
5.16 in.
Joint Angle:
32 degrees
Distance Between Nibbs:
7.63 in.
Use U-Joint Kit:
R676X
Counter Bore Depth:
0.14 in.
Kit Mtg. Holes:
TH
VMRS Code:
024-001-003
Bearing Cap Diameter:
1.94 in.
Use Kit:
KT17SB
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|
| Reference Material: |
For measuring guideline instructions: Click here
|
| Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Other
65437211, E65437211
Model
