Product Details
Specifications
BOM
Where Used
Reference Material
Part Interchange
Status:
Active
Weight:
13.60
Unit Pack:
1
Pallet Quantity:
64
UPC Code:
737238311836
Brand:
Meritor Genuine
Marketing Group:
18N Series
Spline Diameter:
2.024 in.
Number of Splines:
39
Series:
18N
Hub Diameter:
3.00 in.
Spline Length:
2.31 in.
Center To End:
5.19 in.
Counter Bore Depth:
0.12 in.
Use U-Joint Kit:
M281X
Joint Angle:
30 degrees
Comments:
Dana Spline not Involuted
VMRS Code:
024-001-003
Bearing Cap Diameter:
1.94 in.
Yoke Dim. Across Ears:
7.55 in.
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|
| Reference Material: |
For measuring guideline instructions: Click here
|
| Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Dana
6542471, 6542481X, 6543371, 6543371
Other
18N43371RI, 583089C1, 6543381X, 823518N43371, ATI18N43371, TDA18N43371
