Product Details
Specifications
BOM
Where Used
Reference Material
Part Interchange
Status:
Active
Weight:
16.30
Unit Pack:
1
Pallet Quantity:
100
UPC Code:
737238648857
Brand:
Meritor Genuine
Marketing Group:
176N Series
Spline Diameter:
2.390 in.
Number of Splines:
46I
Series:
176N
Hub Diameter:
3.25 in.
Spline Length:
2.88 in.
Center To End:
5.63 in.
Counter Bore Depth:
0.14 in.
Joint Angle:
34 degrees
Use U-Joint Kit:
R677X
Distance Between Nibbs:
7.09 in.
Kit Mtg. Holes:
TH
Comments:
Dana Spline - 2.374 in.-46
VMRS Code:
024-001-003
Bearing Cap Diameter:
1.94 in.
Use Kit:
KT17SB
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|
| Reference Material: |
For measuring guideline instructions: Click here
|
| Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Dana
6342911
Other
176N42911RI, 8235176N42911, ATI176N42911, TDA176N42911
Model
