Locate Dealer / Distributor
Product Details
Specifications
Where Used
Reference Material
Part Interchange
Status:
Active
Weight:
5.85
Unit Pack:
1
Pallet Quantity:
448
UPC Code:
737238467397
Brand:
Meritor Genuine
Marketing Group:
155N Series
Number of Splines:
39I
Series:
155N
Spline Diameter:
2.024 in.
Hub Diameter:
3.00 in.
Spline Length:
2.31 in.
Center To End:
4.75 in.
Joint Angle:
25 degrees
Distance Between Nibbs:
4.97 in.
Counter Bore Depth:
0.09 in.
Use U-Joint Kit:
CP155N or CP155X
Kit Mtg. Holes:
TH
VMRS Code:
024-001-003
Bearing Cap Diameter:
1.38 in.
Use Kit:
KT124
Part Number | Description |
---|---|
SUB155TYS326A | END YOKE |
SUB155TYS326A3 | END YOKE |
155TYS326ABOM | SHAFT ASSY-CROSS/GEAR |
155TYS326AIBOM | YOKE & DEFLECTOR ASSY |
Reference Material: |
For measuring guideline instructions: Click here
|
Xpress Facts: |
Driveline Product Information
|
Competitor
Part Number
Other
8235155TYS326, ATI155TYS326, TDA155TYS326
Model
